进口切割污水泵美国阿卡迪亚品牌

进口切割污水泵Product Description: The cutting pump comprises a pump body, a cutterhead support and an impeller, a chamber for accommodating the impeller is arranged between the pump body and the cutterhead support, a pump shaft driven by a motor is arranged in the pump body, the lower end of the pump shaft extends into the chamber and is connected with the impeller, at the middle water inlet of the cutterhead support and at the water outlet of the chamber, the impeller comprises a impeller disc, a support column and blades, and the support column is arranged in the middle of the impeller disc, At least two blades are axially symmetrically arranged between the support column and the blade disc, the first end of the blade is provided with a first shear edge, the water inlet of the cutter disc support is provided with a cutting cutter disc, the inner side of the cutting cutter disc is provided with at least two blades, the blade is provided with a second shear edge, and the second shear edge forms a shear action with the first shear edge when the impeller rotates. After adopting the principle of scissors, the first and second cutting edges of scissors are relatively sharp, the actual cutting effect is very good, 进口切割污水泵and the overall structure is simple, which is convenient for production and installation. characteristic: Cutting pump is a kind of sewage pump. Compared with ordinary sewage pump, the structure of cutting pump is somewhat different. There is a group of high-strength cutting impeller at the bottom of the body, which can easily cut fiber, feces, branches and other sundries. Due to its small structure and good environmental adaptability, it is widely used in industry, agriculture and daily life. Principle: The cutting pump comprises a pump body, a cutterhead support and an impeller, a chamber for accommodating the impeller is arranged between the pump body and the cutterhead support, a pump shaft driven by a motor is arranged in the pump body, the lower end of the pump shaft extends into the chamber and is connected with the impeller, a water inlet connected with the inlet of the impeller is arranged in the middle of the cutterhead support, and a water outlet connected with the outlet of the impeller is arranged outside the chamber. The impeller includes a impeller disc, a support column and blades, The support column is arranged in the middle of the impeller disc, and at least two blades are axially symmetrical between the support column and the impeller disc, 进口切割污水泵wherein the head end of the blade is connected to the end side of the support column, the connecting side of the blade extends spirally from the side of the support column to the surface of the impeller disc to the edge of the impeller disc, and the bottom side of the head end of the blade forms a first plane flush with the end of the support column, The front side of the head end of the blade forms a second plane with an acute angle with the included angle of the first plane, the first plane and the second plane intersect to form a first cutting edge, a cutting cutter head is arranged at the water inlet of the cutter head support, the cutting cutter head is circular and coaxial with the impeller, the inner side of the cutting cutter head is provided with at least two blades extending inward, and the upper and lower surfaces of the blades are flush with the upper and lower surfaces of the cutting cutter head respectively, An inclined cutting surface is formed on both sides of the blade, the upper end face of the blade intersects with the cutting surface on the side with an acute angle with the upper end face to form a second shear edge, and the second shear edge forms a shear action structure with the first shear edge when the impeller rotates.

（仅供参考）
