全新原装\力士乐\气动\0821003029
类型 4WRA 和 4WRAE直动式二位四通和三位四通比例方向阀，不带电气位置反馈，不带/带集成电子元件（OBE）
公称规格尺寸 6 和 10
组件系列 2X
最大工作压力 315 bar
最大流量： 42 l/min（公称规格尺寸6）
75 l/min（公称规格尺寸10）
特点
– 直动式操作比例方向阀，不带用于类型 4WRAE 的电气位置
反馈和集成电子元件（OBE）
– 控制流体的方向和流量
– 通过带对中螺纹和可拆卸线圈的比例线圈进行驱动
– 用于底板安装：
连接位置符合 ISO 4401
底板符合目录样本 RC 45052（公称规格尺寸6）或 RC 45054（公称规格尺寸10），单独定购
– 弹簧对中控制阀芯
– 控制电子元件
- 4WRAE：
- 集成电子元件（OBE），带电压输入或电流输入（A1 和 F1）
- 4WRA：
- 欧洲板卡标准的数字或模拟放大器（单独定购）
- 模拟放大器模块
二位四通和三位四通比例方向阀设计为底板安装的直动式组件。它们通过带对中螺纹和可拆卸线圈的比例线圈进行驱动。这些线圈由外部控制电子元件（类型 4WRA）或集成的控制电子元件（类型 4WRAE）进行控制。
设计：阀通常由以下部分组成：
– 带安装面的阀体（1）
– 控制阀芯（2），带有压缩弹簧（3 和 4）
– 线圈（5 和 6），带对中螺纹
– 可选集成电子元件（7）
功能：
– 当线圈（5 和 6）断电以后，控制阀芯（2）被压缩弹簧（3和 4）保持在中心位置
– 通过给比例线圈通电直接起动控制阀芯（2）例如，给线圈"b"（6）通电
– 控制阀芯（2）与电气输入信号成比例地向左移动
– 通过具有渐进流特性的类节流孔剖面，P 与 A 相连，B 与 T 相连
– 线圈（6）断电
– 控制阀芯（2）通过压缩弹簧（3）的作用返回中心位置
有 2 个阀芯位置的阀：（类型 4WRA…A…）大体上，此类阀门的功能与带 3 个阀芯位置的阀门功能相对应。但是，带 2 个阀芯位置的阀门仅配有线圈 "a"。其中 公称规格尺寸 6 配备一个插头（8.1），公称规格尺寸 10 配备一个盖（8.2）来代替第二个比例线圈。类型 4WRA 6…-2X/… 的注意事项：要防止油箱管路发生排放。在适当的安装条件下，应安装一个背压阀（背压约为 2 bar）。
4WRA重量 kg 6通经 2.0 ，10通经 6.6
4WRAE重量 kg 6通经 2.2 ，10通经 6.8
以下为在产和停产的一些型号：
R900245449 4WRA10W1-30-2X/G24K4/V-589
R900331078 4WRA10E20-1X/24Z4/M
R900333219 4WRA10E40-1X/24Z4/M
R900333924 4WRA10W40-1X/24Z4/M
R900333926 4WRA10M20-1X/24Z4/M
R900335781 4WRA10E40-1X/24Z4/V
R900337951 4WRA10E40-1X/12NZ4/M
R900338645 4WRA10E20-1X/24NZ4/M
R900339162 4WRA10W10-1X/24NZ4/M
R900339163 4WRA10W20-1X/24NZ4/M
R900340174 4WRA10EB40-1X/24NZ4/M
R900340436 4WRA10W20-1X/24Z4/M
R900340984 4WRA10M40-1X/24Z4/M
R900341058 4WRA10M40-1X/24NZ4/M
R900341918 4WRA10W40-1X/12NZ4/M
R900341986 4WRA10E10-1X/24NZ4/M
R900342192 4WRA10WA10-1X/24NZ4/M
R900342457 4WRA10W10-1X/24N9Z4/M
R900342785 4WRA10M10-1X/24NZ4/M
R900342802 4WRA10M20-1X/24NZ4/M
R900343311 4WRA10EB20-1X/24NZ4/M
R900346120 4WRA10E40-1X/24NZ4/V
R900347162 4WRA10EA20-1X/24Z4/M
R900348449 4WRA10WB40-1X/24NZ4/M
R900350417 4WRA10W3-40-1X/24NZ4/M
R900350879 4WRA10W3-40-1X/24Z4/M
R900350911 4WRA10W1-40-1X/24NZ4/M
R900350976 4WRA10EA40-1X/24NZ4/M
R900351183 4WRA10W20-1X/24NZ4/V
R900352448 4WRA10EA20-1X/24NZ4/M
R900353820 4WRA10WA40-1X/24NZ4/M
R900354532 4WRA10W1-40-1X/24N9Z4/M
R900355401 4WRA10EB20-1X/24Z4/M
R900355527 4WRA10M20-1X/12NZ4/M
R900356946 4WRA10EA40-1X/24Z4/V
R900357218 4WRA10W20-1X/24NK4/M
R900357511 4WRA10E10-1X/24NZ4/V
R900357525 4WRA10W20-1X/24N9K4/M
R900358417 4WRA10EB40-1X/24Z4/M
R900358443 4WRA10E40-1X/24N9K4/M
R900358462 4WRA10EB10-1X/24Z4/V
R900360184 4WRA10W20-1X/24N9Z4/M
R900360988 4WRA10WB20-1X/24Z4/M
R900361957 4WRA10W40-1X/24NZ4/V
R900362001 4WRA10W10-1X/24Z4/M
R900362134 4WRA10W1-20-1X/24NZ4/M
R900364230 4WRA10MB20-1X/24NZ4/M
R900366314 4WRA10V40-1X/24NZ4/M
R900370401 4WRA10E20-1X/24NZ4/V
R900372167 4WRA10EA40-1X/24Z4/M
R900372815 4WRA10WA40-1X/24Z4/M
R900373429 4WRA10WB10-1X/24NZ4/M
R900373430 4WRA10WB20-1X/24NZ4/M
R900374148 4WRA10M10-1X/24NZ4/V
R900374286 4WRA10WA20-1X/24NZ4/M
R900374739 4WRA10M40-1X/24N9Z4/M
R900376936 4WRA10EA10-1X/24NZ4/M
R900378720 4WRA10WA20-1X/24Z4/M
R900380380 4WRA10M40-1X/24J/M
R900380640 4WRA10W40-1X/24N9Z4/M
R900381081 4WRA10EA40-1X/24NK4/M
R900385090 4WRA10W40-1X/24N9K4/M
R900385287 4WRA10E40-1X/24NJ/M
R900387637 4WRA10M20-1X/24N9Z4/M
R900389535 4WRA10E20-1X/24N9Z4/M
R900391784 4WRA10E40-1X/24N9Z4/M
R900392679 4WRA10W10-1X/24NZ4/V
R900392725 4WRA10EA10-1X/24Z4/M
R900393987 4WRA10EB10-1X/24NJ/M
R900394950 4WRA10WB40-1X/24NZ4/V
R900397608 4WRA10W40-1X/24NJ/M
R900403083 4WRA10W1-40-1X/24NZ4/V
R900404545 4WRA10W20-1X/24NJ/M
R900408226 4WRA10EB10-1X/24NZ4/M
R900422240 4WRA10E10-1X/24NJ/M
R900435552 4WRA10W1-40-1X/24Z4/M
R900449775 4WRA10E40-1X/12Z4/M
R900456979 4WRA10WA10-1X/24Z4/M
R900461196 4WRA10EB40-1X/24NZ4/V
R900483531 4WRA10M20-1X/24NZ4/V
R900490492 4WRA10E10-1X/24Z4/M
R900498966 4WRA10W40-1X/24K4/M
R900499561 4WRA10W40-1X/24NZ4/M
R900499700 4WRA10E40-1X/24NZ4/M
R900508218 4WRA10W40-1X/24Z4/V
R900508703 4WRA10W1-20-1X/24NZ4/M
R900511001 4WRA10W2-40-1X/24Z4/M
R900518651 4WRA10V40-1X/24N9Z4/M
R900519168 4WRA10W40-1X/24N9Z4/MR
R900520793 4WRA10E40-1X/24Z4/MR
R900523531 4WRA10W40-1X/24Z4/MR
R900524436 4WRA10EB40-1X/24N9Z4/M
R900525545 4WRA10EA40-1X/24NZ4/V
R900525973 4WRA10E20-1X/24NZ4/MR
R900525976 4WRA10E40-1X/24NZ4/MR
R900525977 4WRA10E20-1X/24NZ4/MR
R900526694 4WRA10W10-1X/24NJ/M
R900529454 4WRA10E10-1X/24NZ4/MR
R900532628 4WRA10WB40-1X/24NJ/M
R900533160 4WRA10W1-40-1X/24NZ4/MR
R900533162 4WRA10W40-1X/24NZ4/MR
R900536530 4WRA10V20-1X/24NZ4/M
R900537146 4WRA10WA40-1X/12N9Z4/M
R900538962 4WRA10W1-10-1X/24NZ4/M
R900539477 4WRA10W40-1X/12Z4/M
R900550894 4WRA10W20-1X/12NZ4/M
R900550895 4WRA10WB40-1X/12NZ4/M
R900558216 4WRA10W40-1X/24N9Z4/V
R900561142 4WRA10W1-20-1X/24NZ4/MR
R900561418 4WRA10EA40-1X/12NZ4/M
R900562030 4WRA10E20-1X/12NZ4/M
R900562141 4WRA10WA10-1X/24NZ4/V
R900563685 4WRA10V10-1X/12Z4/V
R900563963 4WRA10W40-1X/12NZ4/V
R900566682 4WRA10E40-1X/24N9Z4/V
R900566952 4WRA10E1-20-1X/24N9Z4/M
R900569664 4WRA10W2-40-1X/24NZ4/M
R900571823 4WRA10E2-40-1X/24NZ4/M
R900575765 4WRA10W1-60-2X/G24N9K4/V
R900576511 4WRA10W1-20-1X/24N9Z4/M
R900577424 4WRA10W30-2X/G24K4/V
R900577812 4WRA10W20-1X/24NZ4/MR
R900578914 4WRA10W1-10-1X/24Z4/M
R900579170 4WRA10E10-1X/24N9Z4/M
R900580208 4WRA10WB40-1X/24N9Z4/M
R900581203 4WRA10EA40-1X/24NJ/M
R900582097 4WRA10W40-1X/24NK4/M
R900588536 4WRA10E1-40-1X/24N9Z4/M
R900596076 4WRA10EB40-1X/12NZ4/M
R900616773 4WRA10E10-1X/24NK4/M
R900619254 4WRA10E20-1X/24NK4/V
R900733045 4WRA10EB60-2X/G24N9K4/V-589
R900749771 4WRA10E60-2X/G24K4/V-589
R900760427 4WRA10E1-30-2X/G24N9K4/V-589
R900781053 4WRA10W30-2X/G24K4/V-589
R900902097 4WRA10E60-2X/G24N9K4/V
R900905867 4WRA10EA10-1X/24N9Z4/M
R900906030 4WRA10WA60-2X/G24K4/V-589
R900906041 4WRA10W1-20-1X/24Z4/M
R900907370 4WRA10W20-1X/12N9Z4/V
R900907650 4WRA10W60-2X/G24N9K4/V
R900908297 4WRA10E1-30-2X/G24N9K4/V
R900908299 4WRA10W1-30-2X/G24N9K4/V
R900908978 4WRA10E1-60-2X/G24N9K4/V
R900912139 4WRA10EB10-1X/24N9Z4/M
R900914289 4WRA10W3-60-2X/G24N9K4/V
R900917193 4WRA10EA60-2X/G24N9K4/V
R900921739 4WRA10E30-2X/G24N9K4/V
R900922441 4WRA10W30-2X/G24N9K4/V
R900924586 4WRA10WA30-2X/G24N9K4/V
R900926364 4WRA10E40-1X/24NK4/M
R900926365 4WRA10E60-2X/G24N9K4/V-589
R900926985 4WRA10EA30-2X/G24N9K4/V
R900930315 4WRA10E1-40-1X/24Z4/M
R900930773 4WRA10W40-1X/24N9Z4/VR
R900931424 4WRA10M10-1X/24NK4/M
R900931721 4WRA10W60-2X/G24K4/V-589
R900933472 4WRA10V40-1X/24NK4/M
R900934606 4WRA10EB60-2X/G24N9K4/V
R900935623 4WRA10WA60-2X/G24N9K4/V
R900935629 4WRA10W1-30-2X/G24N9K4/V-589
R900935739 4WRA10W1-60-2X/G24N9K4/V-589
R900936632 4WRA10EB30-2X/G24N9K4/V-589
R900938338 4WRA10EA10-1X/24NK4/M
R900943216 4WRA10EB30-2X/G24N9K4/V
R900943416 4WRA10W60-2X/G24N9K4/V-589
R900944543 4WRA10E40-1X/24NK4/MR
R900944554 4WRA10EA60-2X/G24N9K4/V-589
R900944683 4WRA10W1-20-1X/24NK4/MR
R900944775 4WRA10W30-2X/G24N9K4/V-589
R900944997 4WRA10W1-10-1X/24NK4/MR
R900946678 4WRA10W40-1X/24NK4/MR
R900949993 4WRA10E30-2X/G24N9K4/V-589
R900950629 4WRA10WB60-2X/G24N9K4/V
R900950630 4WRA10WB30-2X/G24N9K4/V
R900950732 4WRA10E20-1X/24NK4/M
R900950764 4WRA10W20-1X/24N9K4/M
R900950943 4WRA10W10-1X/24NK4/M
R900951188 4WRA10W40-1X/24NK4/V
R900951267 4WRA10E40-1X/24N9K4/V
R900951926 4WRA10W1-40-1X/24NK4/MR
R900952006 4WRA10E20-1X/24N9K4/M
R900952054 4WRA10WA60-2X/G24K4/V
R900952881 4WRA10EA20-1X/24NK4/M
R900953725 4WRA10WA60-2X/G24N9K4/V-589
R900954060 4WRA10E30-2X/G24K4/V
R900954061 4WRA10E60-2X/G24K4/V
R900954062 4WRA10E1-30-2X/G24K4/V
R900954063 4WRA10E1-60-2X/G24K4/V
R900954064 4WRA10EA60-2X/G24K4/V
R900954065 4WRA10W60-2X/G24K4/V
R900954066 4WRA10W1-30-2X/G24K4/V
R900954067 4WRA10W1-60-2X/G24K4/V
R900954068 4WRA10WA30-2X/G24K4/V
R900954233 4WRA10EB40-1X/24N9K4/V
R900954408 4WRA10EA30-2X/G24K4/V
R900959336 4WRA10E40-1X/24K4/M
R900960286 4WRA10WA10-1X/24NK4/M
R900960321 4WRA10E10-1X/24K4/M
R900960406 4WRA10EA30-2X/G24N9K4/V-589
R900960540 4WRA10W1-40-1X/24N9K4/M
R900960574 4WRA10E1-40-1X/24N9K4/M
R900960823 4WRA10E20-1X/24NK4/MR
R900962127 4WRA10W10-1X/24NK4/V
R900962191 4WRA10W40-1X/24N9K4/V
R900962458 4WRA10WA20-1X/24NK4/M
R900962459 4WRA10WA30-2X/G24N9K4/V-589
R900964918 4WRA10E40-1X/12NK4/M
R900965598 4WRA10E20-1X/24K4/M
R900965714 4WRA10W1-20-1X/24N9K4/M
R900966189 4WRA10E10-1X/24N9K4/M
R900966473 4WRA10W20-1X/24NK4/MR
R900967655 4WRA10EB40-1X/24NK4/M
R900968113 4WRA10W1-10-1X/24N9K4/M
R900968306 4WRA10W20-1X/24NK4/V
R900969821 4WRA10WA40-1X/12NK4/M
R900969840 4WRA10WA40-1X/24K4/M
R900970659 4WRA10E10-1X/24K4/MR
R900970732 4WRA10W60-2X/G24N9K4/V-116
R900970799 4WRA10E10-1X/24NK4/MR
R900971842 4WRA10W10-1X/24K4/M
R900972373 4WRA10W40-1X/12NK4/M
R900973109 4WRA10W10-1X/24N9K4/M
R901033865 4WRA10E30-2X/G24K4/V-589
R901054483 4WRA10EA00-2X/G24K4/V-828
R901056484 4WRA10WB60-2X/G24K4/V
R901085669 4WRA10EA00-2X/G24K4/V-872
R901085689 4WRA10EA00-2X/G24K4/V-873
R901178911 4WRA10W60-2X/G24N9K4/V-660
R901225420 4WRA10W60-2X/G24N9K4/VL
R901232695 4WRA10W1-30-2X/G24N9K4/V-660
R901238074 4WRA10W60-2X/G24N9K4/V-674
R901283306 4WRA10W1-60-2X/G24N9K4/V-660
R901293170 4WRA10W60-2X/G24K4/V-722
R901336859 4WRA10E3-30-2X/G24K4/V-660
